High Speed Full Automatic Paper Rigid Box Making Machine For Gift
Box , Jewellery Box
Automatic Paper Box Making Machine Description:
It adopts visual robot positioning, and can be equipped with a
molding robot holding box structure. Repeated positioning accuracy
is high, and it can work continuously for a long time.
The Automatic Paper Box Making Machine adopts motion controller,
visual manipulator for positioning ,HMI System,which make it
possible that paper feeding, gluing, cardboard four corners taping,
feeding, edge covering, full ear folding, forming and shaping of
the finished box are completed in one operation.Through the
electronic cam gear rack structure driving the box mold to operate,
it can independently complete multiple deep folding operations so
as to meet the requirements of high-end products and boxes free of
folding trace in the market.
characteristics:
using visual robot positioning, positioning accuracy ± 0.1mm;
It is more stable with servo feeder feeding.
Debugging is quick and easy to operate.
Automatic Paper Box Making Machine Parameters:
| Model | ZY-450 |
| Max. size of box | 450x450x120mm |
| Min. size of box | 45x45x8mm |
| Folding-in Depth | 8-120mm |
| Power consumption | 2.0KW |
| Speed | 0-35pcs/min |
| Voltage | AC220V |
| Air consumption | 8L/min 0.65Mpa |
| Weight | 1500kg |
| Measurement: | 7500x1200x1150mm |
Application range:
Mobile phone case, underwear box, gift box, food box, plastic box
This machine is designed for packaging boxes, such as jewellery
box, gift box, mobile box, tea box,etc.
All of the relevant products are internationally high-end products,
low breakdown, high accuracy.
Features:
High Quality Guaranteed
First Class Service
Best Prices
Stable performance
sturdy and durable
Long lifespan
wear resistant
Our service:
Quickly reply to your inquiry
Experienced staff will answer all your questions in a timely
manner.
Our highly trained staff can provide customers with exclusive and
unique solutions.
As an honest seller, we always provide advanced machines to ensure
that our products have high quality and stable functions.
About Us
2019, after 7 years development, we have established perfect sales
network and integrated after-sale service system at domestic and
abroad, which enables the company to provide timely, accurate and
efficient services, and won good customer reputations. The products
are sold all over in China and exported to more than 30 countries
and regions such as Europe, America, Southeast Asia, South America,
Middle East and Africa. The production, sales volume and scale are
all ranked first in the same industry.
For the future development, we will continue to focus on the
“Intelligent Automatic Rigid Box Making Equipment” project, which
will be specialized, refined, strong and long-lasting.
Adhering to the customer's needs as the core, we are committed to
providing high-tech, high-quality rigid box technology solutions,
which will drive the development of the packaging industry.
